1) Input Frequency: 10.70~11.7GHz(LOW BAND);10.70~12.75GHz(HIGH BAND) 2) Output Frequency: 950~1950MHz(LOW BAND);1100~2150MHz(HIGH BAND) 3) LO Frequency: 9.75/10.6GHz;9.75/10.75GHz 4) Noise Figure: 0.2dB(Typ.) 5) Conversion Gain: 70dB(Typ.) 6) F/D Radio: 0.6 7) Input Interface: Wave guide WR-75 8) Cross Pol. Isolation: 20dB(Typ.) 9) Image Rejection: 45dB(Min.) 10) Polarity Switching Voltage:Vertical: 12-14.5V ;Horizontal:16-18V 11) Operating Voltage: Vertical:11.5 ~ 14 Vdc ;Horizontal:16 ~19 Vdc 12) Band Switching Pulse: 0/22kHz tone 13) Gain Flatness: 0.5dB/27MHz 14) D.C.Current Consumption: 160mA(Max.) 15) LO phase noise: -70dB/Hz at 10kHz;-90dB/Hz at 100kHz;-110dB/Hz at 1MHz 16) Output power(at 1dB gain compression): 10dB(Min.) 17) Out put VSWR: 2.5:1(Max.) 18) Output connector: 75 F type female 19) Operating Temperature: -40 ~ +60 20) Storage Temperature: -55 ~ +80
